Eminence N320T-8 High Frequency 2" Compression Driver, 100 Watts at 8 Ohms

Product description

• The 2 in. exit N320T-8 sets a new standard in compression drivers from Eminence. Featuring D3 technology (Damped Diametric Drive), a 3 in. voice coil, and lightweight neodymium ring magnet with copper shorting ring, the N320T-8 offers an ultra-clean sound and low crossover point.
• High frequency driver specifications * Throat Size: 2.00-in , 50.80mm. * Nominal Impedance*: 8.0 Ohms. * Minimum Impedance: 6.7 ohm @ 3.6 kHz . * Power Rating**: 100 W (AES). * Resonance: 0.52kHz. * Usable Frequency Range: 800.0Hz-20kHz. * Recommended Crossover: 800 Hz / 12 dBkHz. * Sensitivity***: 110.40.
• High frequency driver specifications * Magnet Material: Neodymium. * Magnet Weight: 11.00oz, 0.31kg. * Voice Coil Diameter: 3.0-in / 76.20mm. * Voice Coil Former: Polyimide. * Diaphragm Material: Titanium. * DC Resistance (Re): 4.80 Ohms.
• High frequency driver specifications * Overall Diameter: 5.72-in , 145.30mm. * Driver Volume Displaced: 0.02 cu.ft., 0.80 liters. * Depth: 3.10-in , 78.70mm. * Weight: 5.00 lbs, 2.30 kg. * Mounting Thread: N/A. * Mounting Holes Diameter: 4X 1/4-20. * Mounting Holes B.C.D.: 4 in. 101.6 mm .
• Eminence professional audio and musical instrument loudspeakers have been the leading choice in audio applications worldwide. Eminence is dedicated to providing the best quality, value and service to meet your needs.
